REF: 223810001


Frame:

  • Main frame in transversal and longitudinal double C profile tubes, 150x100 mm in high resistance steel of 7 mm thickness.
  • Edged welded steel plate trailed drawbar, fixed to the main frame by coupling pins and double parabolic spring.
  • Rotating greaseable hitch.

Discs:

  • Notched discs in the front body and plain disc in the rear body.
  • 38 mm square discs axles in special treated steel.
  • 38/9“ square 40 mm bearings with 2 taper roller bearings protected by double lip seal on each side.
  • Space between discs: 9”-0.23 m.
  • Finishing disc and hydraulic levelling on all models.

Working angle:

  • Working angle hydraulically adjustable.
  • Hydraulic pening and closing system of the bodies.
  • Working depth mechanical adjustment in the wheel train.

Wheels:

  • Wheels for transport and depth control: 2x400/60-15.5 14T, with hydraulic regulation.
