REF: 225310000


Frame:

  • Rigid one-piece frame in double C profile 200x100 mm made of high elastic steel.
  • Edged welded steel plate trailed drawbar, fixed to the main frame by pivots and double parabolic spring. Rotated grea- sable hitch.


Discs:

  • Notched discs in the front body and plane disc on the rear with 8 mm thickness, on request.
  • 38 mm square discs axles in special treated steel.
  • 38/9 “ bearings square of 40 mm with 2 taper roller bearings protected by double lip seal.
  • Space between discs: 9” – 0,23 m.
  • Finishing disc.


Working Angle:

  • Hydraulic gang angling of the working angle.
  • Hydraulic adjustment of the working depth.


Wheels:

  • Transport and depth control wheels with hydraulic drive: 2x400/60 15.5 14T in the models of 38, 42 and 46 discs, 2x500/50 17 14T in the models of 50 and 54 discs.
