CGG


Quantity:

Add

REF: 394510000A


Main set:

  • 14000, 16000 and 18000 L capacity models.
  • Deposit in hot-galvanized steel plate (interior/exterior).
  • Spring loaded lance with hydraulic shoes.
  • Bogie-type suspension (optional auto-steer, forced directional)
  • Rear door (man carrier) with opening for cleaning with Ø800mm.
  • Configurable wheels.
  • PVC mudguards.


Pump:

  • Compressor/depressor pump, oversized drive to the tractor’s power take-off, 540 r.p.m. • Various pumps available with a wide range of options.
  • Fusible cardan or homokinetic transmission (standard on CG 18000).
  • Hydraulic reverser (standard on CG 18000).


Safety:

  • Hydraulic brake with spring retriever.
  • Mechanical parking brake as standard.
  • Safety valves (pressure/depressurize).
  • Manavacuometer.
  • 2 or 3 interior bulkheads, depending on model.
  • Tubular level indicator with Ø100mm
  • Safety devices, signalling and lighting.

Various:

  • 3 m flexible filler pipe, with quick coupling.
  • Hose supports (single supports, shelves).
  • Mechanical side valve and hydraulic rear valve 200mm (8”) (optional 150mm (6”))


Pre-installation for:

  • Loading arm with the possibility of mounting on the left or on the right.
  • Various types of Slurry applicators (distribution bars and Vogelsang locators).
  • Total vacuum system.
  • Garda systems (cannon, recirculation, fire hydrant).
  • Pneumatic stirrer.
  • Side ladders, toolbox and handrinse basin.


Modifications to the standard equipment:

  • Rigid/revolving linkage amendment
  • Cardan amendment
  • Pumps amendment
  • Sluice gates amendment
  • Wheel amendment


Load Arm

  • One or two joints;
  • Load accelerator;
  • Manual/automatic purge;
  • Various accessories at the end of the loading arm;


Garda Systems

  • Hydraulic cannon with 1 or 2 movements;
  • Fire hydrant (Storz outlet);
  • Hydraulic stirrer
  • Recirculation via Garda;


Slurry Applicators

  • Fans (single fixed, double fixed);
  • Distribution bars;
  • Vogelsang UniSpread locators
  • Hydraulic multi-function control
  • Pneumatic stirrer
  • Full vacuum system
  • Boom with hydropneumatic suspension
  • Suction station (hopper)
  • Hopper lifting and transport system Camera + Monitor
  • Ladders
  • Metal side shelves
  • Handrinse basin
  • Tool Case
  • Flashing lamp
  • Work Lamp
  • Wheel chocks
