REF: 224500003


Frame:

  • Main frame in transversal and longitudinal tubes.
  • Edged welded steel plate trailed drawbar, fixed to the main frame by coupling pins and double parabolic spring.
  • Rotating greaseable hitch.

Discs:

  • Notched or plane discs in the front body and plane disc on the rear with 6 mm thickness.
  • 38 mm square discs axles in special treated steel.
  • Bearings 38/9” square 40 mm in disc harrows of 26” and 38/9” square 40 mm, box of 32 mm in the discs harrows with 24”.
  • 2 taper roller bearings protected by double lip seal on each side.
  • Space between discs: 9” – 0.23 m.
  • Finishing disc.

Working angle:

  • Hydraulic opening of disc bodies.

Wheels:

  • Transport and depth control wheels: 2x10.0/75-15 12T, with hydraulic adjustment of the train.
